OEM Type Pockels Cell Drivers DPB-3-8.6
EKSMA Optics
| Product number | DPB-3-8.6 |
| Quantity unit | pc |
| Max HV operating voltage, kV: | 8.5 |
| Max HV repetition rate: | 3 kHz |
| HV Power Supply: | Not Included |
| Maximum output pulse amplitude (HV), kV: | 8.6 |
| HV operation voltage range: | 10,5 ns |
| HV program input signal range: | 9,5 ns |
| HV pulse duration: | 35...2000 ns |
| HV pulse delay: | 30 ns |
| Output polarity: | Bipolar |
| Requirement for external triggering pulse amplitude: | 3,5...5 V (50 Ω load) |
| Requirement for external triggering pulse rise time: | ≤5 ns |
