Encased Pockels Cell Drivers with Integrated HV Power Supply HVS-D2-10-4.2
EKSMA Optics
| Product number | HVS-D2-10-4.2 |
| Quantity unit | pc |
| Max HV operating voltage, kV: | 4.2 |
| Max HV repetition rate: | 10 kHz |
| HV Power Supply: | Integrated |
| Maximum output pulse amplitude (HV), kV: | 4.2 |
| HV operation voltage range: | 6 ns |
| HV program input signal range: | 6 ns |
| HV pulse duration: | 30...3000 ns |
| HV pulse delay: | 30 ns |
| Output polarity: | Bipolar |
| Requirement for external triggering pulse amplitude: | 3,5...5 V (50 Ω load) |
| Requirement for external triggering pulse rise time: | ≤10 ns |
